EVGA nForce 780i SLI Motherboard
The Ultimate GPU Motherboard
The Ultimate GPU Motherboard

Introducing the EVGA nForce 780i SLI Motherboard

EVGA is proud to announce its new flagship motherboard; the EVGA 780i SLI; featuring three 16x PCI express slots, PCI express 2.0, and full support for Intel 45nm Core 2 CPU's. The three 16x PCI express slots provide the best platform for NVIDIA 3-way SLI; the latest in SLI technology. The EVGA 780i is ESA (Enthusiast System Architecture) certified which provides the best monitoring and fine tuning of your PC.

Click to enlarge Click to enlarge Click to enlarge

Engineered For The Enthusiast
  • Extreme FSB speeds plus support for the latest 45nm Intel Core 2 platform

  • Extreme DDR2 speeds with support for up to 1200MHz SLI-Ready memory

  • Three 16x PCI Express 2.0 slots for unmatched 3-way SLI performance

Maximizes performance for the gaming enthusiast
  • The combination of NVIDIA nForce MCPs and GeForce GPUs deliver the ultimate PC gaming experience

  • SLI-Ready memory with EPP increases the bandwidth of memory buses with one click implementation.

Features and Benefits:
  • NVIDIA SLI certified

  • Intel socket 775

  • 45nm CPU ready (Yorkfield & Wolfdale)

  • Includes 3-Way & 2-Way SLI Bridge

  • PCI Express 2.0 support

  • ESA Certified

  • 6 SATA-2 ports with support for RAID 0, 1, 0+1, 5, JBOD

  • HD Audio - 7.1 Channel

  • 2 Gigabit Ethernet

PCI Express 2.0:
    When using this platform with an EVGA PCIe 2.0 graphics card; double the bandwidth is achieved. With up to 16GB/s of bandwidth and advanced power management features, PCIe 2.0 is the ultimate interface for enthusiasts.
    PCIe 2.0 is entirely backwards compatible, meaning a PCIe 2.0 card or motherboard will work with any PCIe device and visa versa.

nForce 780i SLI
Part Number 132-CK-NF78-A1
CPU Support Intel Socket 775
Chipset NVIDIA nForce 780i SLI Chipset
Memory Support DDR2 533/667/800/1200MHz SLI-Ready memory
FSB Speed Supports 533/800/1066/1333 Mhz
SATA Header 6
SATA Type 300MB/sec
USB Ports 10
PCIE Slot 3 x PCIe x16, 1 x PCIe x1, 2 x PCI
Integrated LAN 2 x 10/100/1000
Product Warranty Limited Lifetime warranty
upon registration

Article Viewed: 670152 times since 12/17/2007 7:00:00 AM
