EVGA SuperNOVA 550 G3, 80 Plus Gold 550W, Fully Modular, Eco Mode with New HDB Fan, 7 Year Warranty, Includes Power ON Self Tester, Compact 150mm Size, Power Supply 220-G3-0550-Y1

EVGA SuperNOVA 550 G3, 80 Plus Gold 550W, Fully Modular, Eco Mode with New HDB Fan, 7 Year Warranty, Includes Power ON Self Tester, Compact 150mm Size, Power Supply 220-G3-0550-Y1

*Accessories shown in the images above are subject to change without notice.

P/N: 220-G3-0550-Y1

Out of Stock



Original price:

Current price:
$119.99

Purchase from our Partners

Comparison Chart

EVGA 550 Watts Power Supply Part Number Efficiency ECO Mode Modular Warranty +12V Rail Rating Fan Size Japanese Capacitors
EVGA SuperNOVA 550W GT Power Supply 220-GT-0550 Gold Auto Full 7 Year(s) 45.8A 135mm 100%
EVGA SuperNOVA 550W GA Power Supply 220-GA-0550 Gold Yes Full 10 Year(s) 45.8A 135mm 100%
EVGA SuperNOVA 550W GM Power Supply 123-GM-0550 Gold Auto Full 7 Year(s) 45.8A 92mm 100% on Main PCB
EVGA SuperNOVA 550W G3 Power Supply 220-G3-0550 Gold Yes Full 7 Year(s) 45.8A 130mm 100%
EVGA 500 GD Power Supply 100-GD-0500 Gold No No 5 Year(s) 41.6A 120mm Main
  • Overview
  • Specs
  • Features
  • Awards
  • Compatibility
View detailed feature information for EVGA SuperNOVA 550 G3, 80 Plus Gold 550W, Fully Modular, Eco Mode with New HDB Fan, 7 Year Warranty, Includes Power ON Self Tester, Compact 150mm Size, Power Supply 220-G3-0550-Y1

Cable Length

ATX Cable 1x 600mm
EPS Cable 1x 700mm
PCIe Cable 1x 600mm, 1x 600mm, 750mm
SATA Cable 2x 500mm, 600mm, 700mm
Four-Pin Peripheral Cable 1x 500mm, 600mm, 700mm, 800mm
Floppy Adapter 1x 100mm
AC Power 1x 1500mm
Modular Cable Type Full

Connector Quantity

24 Pin ATX 1x
EPS (CPU) 1x 8pin (4+4)
PCIe 3x 8pin (6+2)
SATA 6x
Four-Pin Peripheral 4x
Floppy 1x

Power Specs

AC Input 100 - 240 VAC, 10A, 50 - 60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 22A 22A 45.8A 3.0A 0.5A
549.6W
110W 549.6W 15W 6W
Total 550W @ +50C

Additional Details

Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net Weight 4.70 lbs
Size 85mm (H) x 150mm (W) x 150mm (L)
Approvals CB, CE, FCC, RCM, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Fan Size / Bearing 130mm Hydraulic Dynamic Bearing

Product Warranty

This product comes with a 7 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.

  • 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads

  • Highest quality Japanese brand capacitors ensure long-term reliability

  • Fully Modular to reduce clutter and improve airflow

  • NVIDIA SLI & AMD Crossfire Ready

  • Unbeatable EVGA 7 Year Warranty and unparalleled EVGA Customer Support.

  • Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)

  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads

  • Hydraulic Dynamic Bearing Fan for ultra-quiet operation and increased lifespan.

Awards of the EVGA SuperNOVA 550 G3, 80 Plus Gold 550W, Fully Modular, Eco Mode with New HDB Fan, 7 Year Warranty, Includes Power ON Self Tester, Compact 150mm Size, Power Supply 220-G3-0550-Y1 (220-G3-0550-Y1)

  • PC Perspective

    2016/12

    PC Perspective
    The EVGA 550W Supernova G3 power supply exhibited outstanding voltage regulation on all of the DC outputs along with excellent AC ripple and noise suppression. The power supply features a good assortment of modular cables and delivers great efficiency, easily meeting the 80Plus Gold criteria.

Compatibility of the EVGA SuperNOVA 550 G3, 80 Plus Gold 550W, Fully Modular, Eco Mode with New HDB Fan, 7 Year Warranty, Includes Power ON Self Tester, Compact 150mm Size, Power Supply 220-G3-0550-Y1 (220-G3-0550-Y1)

Operating System Support

Requirements

Product Warranty

  • This product comes with a 7 year limited warranty with registration.
    EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.
