EVGA nForce 790i Ultra SLI Motherboard
The Ultimate GPU Motherboard
The Ultimate GPU Motherboard

Introducing the EVGA nForce™ 790i Ultra SLI Motherboard

EVGA is happy to announce the 790i Ultra SLI motherboard, foundation for the worlds fastest gaming PCs, delivering top performance for 1600 MHz FSB Intel CPUs with extreme CPU overclocking, and unmatched gaming for 2-way, 3-way and Quad SLI technology. EVGA 790i Ultra offering new DDR-3 Technology supporting up to 2GHz providing world-record setting memory speeds and component control with ESA (Enthusiast System Architecture).

Click to enlarge Click to enlarge Click to enlarge

NVIDIA nForce 790i Ultra SLI, the foundation for ultimate gaming:
  • Build the fastest, most overclockable rig for 1600MHz FSB and beyond.

  • Reach maximum performance with the world record setting DDR3 memory speeds.

  • Achieve ultimate control with the real-time component monitoring and tuning features of ESA.

  • Experience unmatched gaming for 2-way, 3-way, and Quad SLI.

Features and Benefits:
  • NVIDIA SLI certified

  • Intel socket 775

  • 45nm CPU ready (Yorkfield & Wolfdale)

  • Includes 3-Way & 2-Way SLI Bridge

  • PCI Express 2.0 support

  • ESA Certified

  • 7 SATA-2 ports with support for RAID 0, 1, 0+1, 5, JBOD

  • (1) External SATA port

  • HD Audio - 7.1 Channel

  • (2) Gigabit Ethernet ports

CPU Compatibility List

PCI Express 2.0:
    When using this platform with an EVGA PCIe 2.0 graphics card; double the bandwidth is achieved. With up to 16GB/s of bandwidth and advanced power management features, PCIe 2.0 is the ultimate interface for enthusiasts. PCIe 2.0 is entirely backwards compatible, meaning a PCIe 2.0 card or motherboard will work with any PCIe device and visa versa.
EVGA 790i + 9800GX2 + KINGPIN = 3DMark06 World Record
nForce 790i Ultra SLI
Part Number 132-CK-NF79-A1
CPU Support Intel Socket 775
Chipset NVIDIA nForce 790i Ultra SLI Chipset
Memory Support DDR3 1066/1333/1600/2000 MHz
FSB Speed Supports 800/1066/1333/1600 Mhz
SATA Header 7
SATA Type 300MB/sec
USB Ports 10
PCIE Slot 3 x PCIe x16, 2 x PCIe x1, 2 x PCI
Integrated LAN 2 x 10/100/1000
Product Warranty Limited Lifetime warranty
upon registration
