EVGA SuperNOVA 1200 P2 Power Supply

P/N: 220-P2-1200-X1

View Spec Sheet
Download PDF Manual

$249.99

select
EVGA 220-P2-1200-X1  SuperNOVA 1200 P2 Power Supply
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 1
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 2
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 3
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 4
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 5
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 6
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 7
  • EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1) - Image 8

*Accessories shown in the images above are subject to change without notice.

Where To Buy

  • Amazon
  • Micro Center
  • NCIXUS
  • Newegg
EVGA 1200 Watts Power Supply Part Number Efficiency ECO Mode Modular Warranty +12V Rail Rating Fan Size Japanese Capacitors Performance
EVGA SuperNOVA 1300 G2 Power Supply 120-G2-1300 Gold No Full 10 Year(s) 108.3A 140mm 100% Better
EVGA SuperNOVA 1200 P2 Power Supply 220-P2-1200 Platinum Yes Full 10 Year(s) 99.9A 140mm 100% Best

Cable Length

ATX Cable 1x 600mm (m)
EPS Cable 2x 750mm (m)
PCIE Cable 2x 750mm, 900mm (m) 4x 750mm (m)
SATA Cable 4x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable 1x 550mm, 650mm 750mm (m) 1x 550mm,650mm (m) (f)
Floppy Adapter 1x 100mm
AC Power 1x 1500mm (m)
Modular Cable Type Full

Connector Quantity

24 Pin ATX 1x
EPS (CPU) 2x 8pin (4+4)
PCIE 6x 8pin (6+2), 2x 6pin
SATA 12x
Four-Pin Peripheral 5x
Floppy 1x

Power Specs

AC Input 100 - 240 VAC, 15A, 50 - 60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 20A 20A 99.9A 2.5A 0.5A
99.9A
100W 1198.8W 12.5W 6W
Total 1200W @ +50C

Additional Details

Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net Weight 10 lbs
Size 85mm (H) x 150mm (W) x 200mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, BSMI, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Fan Size / Bearing 140mm Double Ball Bearing

Product Warranty

This product comes with a 10 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.

Unbeatable 10 Year Warranty and unparalleled EVGA Customer Support

Highest quality Japanese brand capacitors ensure long-term reliability

Fully Modular to reduce clutter and improve airflow

NVIDIA SLI & AMD Crossfire Ready

Double Ball Bearing fan for exceptional reliability and quiet operation

Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)

80 PLUS Platinum certified, with 92% (115VAC) / 94% (220VAC~240VAC) efficiency or higher under typical loads

Awards of the EVGA SuperNOVA 1200 P2 Power Supply (220-P2-1200-X1)

KitGuru

2014/12/01

Considering it will deliver in excess of 1,300 watts while performing so exceptionally well in all key areas, it deserves our highest award. It is pretty much the best £200 you could spend for a new high end Crossfire or SLI system build.
bit-tech

2014/09/01

The SuperNova’s performance is excellent, delivering its rated power without breaking a sweat or dropping a voltage below 12V, coming in at 91.29 percent efficiency and having a nice low ripple of 26.8 mVpp under maximum load.
PC Perspective

2014/09/01

The SuperNOVA 1200 P2 power supply exhibited outstanding voltage regulation with very low AC ripple, even at full load.
TechPowerUp

2014/08/01

EVGA's new flagship PSU is among the best I have ever tested … EVGA offers it at a very good price which will make the competition cringe…
HiTechLegion

2014/08/01

The SuperNova 1200 P2 is an absolute monster in terms of power, but it also has the performance and efficiency to go with it.
JonnyGURU

2014/07/01

This unit has nothing working against it. Nothing. It has no competition from anything even close to its price point.
