EVGA SuperNOVA 1300 G2 Power Supply

P/N: 120-G2-1300-XR

View Spec Sheet
Download PDF Manual

$219.99

See price in cart

(with Instant Rebate)

select
EVGA 120-G2-1300-XR  SuperNOVA 1300 G2 Power Supply
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 1
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 2
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 3
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 4
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 5
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 6
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 7
  • EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR) - Image 8

*Accessories shown in the images above are subject to change without notice.

Promos

Where To Buy

  • Amazon
  • Micro Center
  • NCIXUS
  • Newegg
EVGA 1300 Watts Power Supply Part Number Efficiency ECO Mode Modular Warranty +12V Rail Rating Fan Size Japanese Capacitors Performance
EVGA SuperNOVA 1300 G2 Power Supply 120-G2-1300 Gold No Full 10 Year(s) 108.3A 140mm 100% Better
EVGA SuperNOVA 1200 P2 Power Supply 220-P2-1200 Platinum Yes Full 10 Year(s) 99.9A 140mm 100% Best

Cable Length

ATX Cable 1x 600mm (m)
EPS Cable 2x 750mm (m)
PCIE Cable 2x 750mm, 900mm (m) 4x 750mm (m)
SATA Cable 4x 550mm, 650mm, 750mm (m)
Four-Pin Peripheral Cable 1x 550mm, 650mm, 750mm (m) 1x 550mm, 650mm (m) (f)
Floppy Adapter 1x 100mm
AC Power 1x 1500mm (m)
Modular Cable Type Full

Connector Quantity

24 Pin ATX 1x
EPS (CPU) 2x 8pin (4+4)
PCIE 6x 8pin (6+2), 2x 6pin
SATA 12x
Four-Pin Peripheral 5x
Floppy 1x

Power Specs

AC Input 100 - 240 VAC, 15A, 50 - 60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 24A 24A 108.3A 3A 0.5A
108A
120W 1299.6W 15W 6W
Total 1300W @ +50C

Additional Details

Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode No
MTBF 100,000 Hours
Net Weight 8 lbs
Size 85mm (H) x 150mm (W) x 200mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, BSMI, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Fan Size / Bearing 140mm Double Ball Bearing

Product Warranty

This product comes with a 10 year limited warranty with registration.
EVGA offers several warranty solutions for our customers to choose from. Please refer to the suffix of the part number and our Warranty Terms for details.

Unbeatable 10 Year Warranty and unparalleled EVGA Customer Support

80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads

Highest quality Japanese brand capacitors ensure long-term reliability

Fully Modular to reduce clutter and improve airflow

NVIDIA SLI & AMD Crossfire Ready

Double Ball Bearing fan for exceptional reliability and quiet operation

Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), and SCP (Short Circuit Protection)

Awards of the EVGA SuperNOVA 1300 G2 Power Supply (120-G2-1300-XR)

Hardware.Info UK

2013/10/01

The EVGA SuperNova 1300W is an excellent power supply with almost Platinum-like efficiency, an extremely low ripple and good voltages. Gamers and overclockers with multiple video cards can eat their heart out with this PSU.
JonnyGURU

2013/08/01

This... is the power supply to beat at the 1300 watt level right now. It is that damn good. This is the power supply that makes you say, "screw Platinum efficiency, I'm getting an EVGA G2 1300 instead." Heck, I want one, and I already have one.
TechPowerUp

2013/08/01

EVGA managed to deliver a very strong PSU of excellent quality at a bargain price.
